E12W
Compact, Stylish and Versatile Wi-Fi Video Door Phone for Every Front Door
Akuvox E12W is a single-button SIP video door phone designed for all types of front doors, including houses, apartments, and condos. Despite its slim body, it offers many cutting-edge features, such as mobile access, wireless communication, and Wi-Fi connectivity.
Akuvox E12W helps users control who enters the building while allowing residents to verbally and visually confirm visitors’ identities. When the bell is rung, E12W alerts users and lets them see and speak with visitors from their smartphone, from anywhere.
E12W
at a Glance
Body Material
Plastic
Wiegand Port
1ch input/output selectable
TF Card Slot
1
Camera
2M pixels, automatic lighting
RF Reader
13.56MHz & NFC only Android
Relays Out
1
Microphone
1
Button
1 call button
Light Sensor
Support
Inputs
2
Speaker
1
Perfect Doorphone Choice for Daily Life
Akuvox E12W is designed to provide convenient and secure door communication for daily use. With its single-button design, wide-angle camera, two-way audio communication, and smartphone-based access, it is suitable for residential environments such as houses, apartments, and condominiums.
- Single button for outdoor environment
- Linux operation system
- Wide-angle camera: 123º (H), 69º (V)
- Two-way audio communication over IP networks with Echo Cancel feature
- Surface-mounted
- Complies with SIP & ONVIF
Tech-forward Mobile Access
This stylish door phone offers smartphone-based access using Bluetooth, mobile app, and NFC, in addition to traditional RFID cards. With Bluetooth credentials, users simply wave their smartphone for access.
Mobile app
IC Cards
NFC
Bluetooth
Remote Door Management
When connected to the Akuvox SmartPlus cloud service, residents can remotely communicate with visitors, grant door access, and monitor doorstep activities using the SmartPlus App on their smartphones, from anywhere and at any time.
Built for Outdoor Use
With an IP65 rating, high UV resistance, and a wide temperature range from -40°C to +60°C, Akuvox E12W is built to withstand various outdoor elements such as rain, heat, snow, dust, and dirt.
Award-Winning Modern Design
This stylish and compact design, honored with the Germany Red Dot Design Award, Germany iF Design Award, and Japan Good Design Award, seamlessly complements contemporary architectural spaces.
Key Specifications of Akuvox E12W
Item
Details
Body Material
Camera
2M pixels, automatic lighting
Viewing Angle
123°(H) / 69°(V)
Button
1 call button
RF Reader
13.56MHz & NFC only Android
Wiegand Port
1ch input/output selectable
Relays Out
1
Inputs
2
TF Card Slot
1
Microphone
1
Speaker
1
BLE
Support BT5.0
Wi-Fi
IEEE802.11a/b/g/n/ac/ax, 2.4GHz & 5GHz
Ethernet Port
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
Power Input
12V DC connector if not using PoE
IP Rating
IP65
Installation
Wall-mounted
Dimension
146 x 70 x 23 mm
Working Humidity
10~90%
Working Temperature
-40°C ~ +60°C
Storage Temperature
-40°C ~ +70°C
